200R 700R4 Night Stalker Series 200 RPM Over Stock Towing Lock Up Torque Converter Part Number 4840HD GM

Description

GM
Chevy
700R4
200R
298mm
Part Number 4840HD
NIGHT STALKER SERIES
(LT type Engines)
For the 3 step input shaft
Stall Range: 200 – 300 RPM Over Stock
Factory 12 inch Core
Bolt Circle: 10.75 inches
27 Spline Input Shaft (Count The Smaller splines, Tops of each tooth)
Torrington Style Incased Bearings
Modified Heavy Duty Stator
Extreme Duty Lock Up
Extreme Temp Heavy Duty O-ring
Factory 1.703 inch Crank Pilot
Bolt Size: 10MM X 1.5 Pitch
No – Anti-Balloon Plates
Quality Inspections at Every Step
Leak & Pressure Tested
Digitally Balanced
4 Corner tac Welded Fins or Furnace Brazed
Tip : Use Type F Transmission Fluid For Best Results.
TIP : Always Use an Additional Transmission Cooler
TIP : Use Blue Loctite

MADE IN THE USA

* NOTE : ALL Advertised stalls are based on a specific vehicle’s setup. All stall ranges will vary depending on your vehicle’s setup. Please contact us for more information 888-267-7464

Building High Performance & Racing Converters Since 1970!

We recommend upgrading to a “Street Bandit Series” torque converter if you have upgraded intake, headers, exhaust, cam, or gearing.

We recommend upgrading to an “Out Law Series” torque converter if you have any power adders like Nitrous (NOS), Turbocharger(s), Supercharger, or a Trans Brake
