2004R 700R4 298mm Out Law 32-3,500 RPM Lock Up Racing Torque Converter Part Number 48764 GM

Description

GM
Chevy
700R4
200R
298mm
Part Number 48764
OUT LAW RACING SERIES
298mm (LT type Engines)
For the 3 step input shaft
Super Lightweight Converter
Stall Range: 3,200 – 3,500 RPM
9.6 inch Core
Bolt Circle: 10.75 inches
27 Spline Input Shaft
NOTE: Count The Smaller Set of Splines, Tops of Each Tooth
Torrington Style Incased Bearings
Modified Extreme Duty Stator
Extreme Duty Lock Up
* We Deleted the Need for the End of the Input shaft O-Ring
* Lock Up is sealed on the back side of our Turbine
1.703 inch Crank Pilot Precision CNC Machined
Bolt Size: 3/8 X 16 TPI (GRADE 8 ONLY)
Yes – Anti-Balloon Plates Precision CNC Machined
Whole Back Cover Quenched and Hardened
ALL of the Pump & Turbine Fins are Welded or Furnace-Brazed
Quality Inspections through out Every Step
For Choppy Cams and Lightweight vehicles
Leak & Pressure Tested
Digitally Balanced
Great with Nitrous, Turbo, Super Charger, & Trans-Breaks
TIP : Use Type F Transmission Fluid For Best Results
TIP : Always Use an Additional Transmission Cooler
TIP : Use Blue Loctite
